Description
The Yamaha RSio64-D - the most recent addition to the R series - is an audio interface that converts between Dante and Mini-YGDAI formats for up to 64 inputs and 64 outputs, providing enhanced flexibility for sound systems that include a Dante audio network. Pairing the RSio64-D interface with Dante/Mini-YGDAI card conversion allows for use across many professional audio applications - including live sound, broadcast and recording - with an array of I/O and processing options offered by more than 30 different Mini-YGDAI cards. What's more is those cards are not just limited to I/O cards that handle AES/EBU or ADAT formats, but also processing cards that provide capabilities such as Lake processing and Dan Dugan automatic mixing.
Includes
Owner's Manual
AC power cord
Yamaha RSio64-D Features:
- Mini-YGDAI cards offer a multitude of I/O and processing options
- Seven general routing presets, including routing between Mini-YGDAI cards
- Supports full matrix patching from R Remote V3 or a CL/QL series console
- Sample rate converters for all four Mini-YGDAI slots
- EXT DC INPUT for redundant power supplies
- Supports Dante redundancy
Tech Specs
| Sampling frequency rate | External 44.1kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 48kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 88.2kHz : +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 96kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) |
| SRC | SRC Lock Range: 39.7 kHz - 101.7 kHz, Sample Rate Ratio Limit: 1:2.6 to 2.6:1 |
| Power requirements | 100-240 V 50/60 Hz |
| Power consumption | 60 W |
| Dimensions | W: 480mm H: 88mm D: 365mm |
| Net weight | 6.1kg |
| Accessories | Owner's Manual, AC power cord |
| Others | Operating temperature range: 0 - 40 |
| Storage temperature range: | -20° - 60° |
