KEY FEATURES
- Premium, ultra-low noise and high headroom studio control and communication center
- All-in-one master volume controller, source selector, monitor switcher and talkback box
- 2 state-of-the-art, Midas mic preamplifiers with +48 V phantom power
- Audiophile 192 kHz 2x2 USB audio interface, perfect for computer-based studios
- True VCA control for extremely precise level control and stereo tracking
- 4 inputs with level controls plus additional USB monitoring from your DAW
- 2 independent and adjustable monitor outputs to connect up to 2 sets of studio monitors
DESCRIPTION
Midas Mic Preamp – Legend Inside!
Did you know that Midas is one of the most recognized brands used by audio professionals around the world? Now you can get the gear the pros use! STUDIO L comes with two state-of-the-art Midas microphone preamplifiers with +48 V phantom power, ultra-low noise, high gain and audiophile quality.
The STUDIO L is the ideal solution for home or professional studios, or as part of a larger setup. Premium, ultra-low noise components and high headroom lets your music shine at its best – this is especially true for one of the most critical sources: Vocals!
Crystal Clear Signal Path at 192 kHz
The STUDIO L is more than just a monitor controller – we added one of the best USB audio interfaces with the highest possible resolution and lowest latency. Full 192 kHz sampling rate at a clear 24-bit resolution will make you smile listening to the crisp and astonishing sound you’ll get.
VCA-Control – Not Just a Volume Knob
Unlike the typical and inexpensive potentiometers used by our competitors, the STUDIO L utilizes high-end Voltage Controlled Amplifier (VCA) technology. While conventional monitor controllers directly pass the signal through the volume potentiometer, the STUDIO L controls a separate high-precision amplifier circuit that drives the volume change. For perfect stereo and phase coherency, precision level adjustment, accurate sound and no quality degradation over time.
The All-In Device
The STUDIO L integrates seamlessly into your existing setup. You can even make it the center piece of your studio. Thanks to the built-in audio interface and Midas microphone pre-amps it becomes an all-in-one recording solution, just add your computer and you’re ready to go.
More Monitor Options
Today’s recordings have to sound great everywhere: in the car, at home, on your cell phone, soundbar, Bluetooth speakers and in the club – so experiencing your mix through as many speaker systems as possible is more essential than ever.
High Quality, Best Value
The STUDIO L to provide many years of super-clean, high-fidelity performance in the most critical listening environment – yours! Built from the highest-grade components, STUDIO L is the perfect way to add a lot more convenience into your current studio setup.
SPECIFICATIONS
|
Inputs |
|
| Inputs |
4 |
| Preamps |
2 x Midas designed |
| Type |
2 x XLR / TRS combo connector (mic/line) |
| Impedance |
Mic: 3 kΩ / Line: 1 MΩ |
| Line inputs |
2 x 1/4" TRS, balanced or unbalanced, +4/-10 dB 1 x 1/8" TRS stereo (input 3/4) |
| Maximum input level |
+22 dBu |
| Outputs | |
| Outputs |
3 stereo |
| Line outputs |
6 x 1/4" TRS, balanced or unbalanced |
| Headphone outputs |
2 x 1/4" TRS stereo |
| Maximum output level |
+22 dBu |
| USB | |
| Type |
Class compliant USB 2.0, type B |
| Supported operating systems |
Windows 10/ Mac OS X 10.14 or higher |
| Audio |
2 in / 2 out |
| Converter resolution |
24-bit |
| Supported sample rate |
44.1, 48, 88.2, 96, 192 kHz |
| Talkback Section | |
| Output level |
-∞ to +10 dB |
| Talback level |
-∞ to max |
| Takback destination |
cue |
| Controls | |
| Phantom power |
+48 V (inputs 1/2) |
| Volume |
High-precision stereo tracking VCA volume control 0 - 100% |
| Playback controls |
Mono, Mute, Dim |
| Monitor select |
A, B |
| Input 1/2 |
48 V on/off, Stereo on/off, 1/2 (channel select) on/off |
| Input 3/4 |
-12 to +12 dB Trim, 3/4 (channel select) on/off |
| USB input |
USB (channel select) on/off |
| Muted |
-60 dB |
| Dim |
-20 dB |
| Direct monitoring |
Inputs to Cue blend |
| Phones 1/2 |
Level control -∞ to max, common source select |
| System | |
| Frequency response |
20 Hz to 20 kHz (±0.5 dB) |
| Signal-to-noise ratio |
<-90 dBu RMS, un-weighted |
| Distortion (THD+N) |
<0.01% @ 1 kHz, unity gain, 4 dBu input |
| Crosstalk |
<-60dB @ 1 kHz, unity gain, 4 dBu input |
|
Power Requirements |
|
| Mains voltage |
100-240 V, 50/60 Hz |
| Power supply |
12 V DC 2000 mA |
| Power consumption |
18 W max |
| Physical | |
| Standard operating temperature range |
5° C – 45° C (41° F – 113° F) |
|
Dimensions |
80 x 252 x 163 mm (3.15 x 9.92 x 6.42") |
| Weight |
1.5 kg (3.53 lbs) |
