Audio-Technica ATW-1312 Digital Wireless System

Delivery, Warranty & Returns Information

Clear and natural High-fidelity sound.

The Audio-Technica "System 10 Pro" rack-mountable digital wireless system is so simple to use, so dependable and so automatic that you'll never have to think about it. Set it up anywhere, turn it on and it's good to go.

Product Highlights:

  • 2.4 GHz 24-bit / 48kHz Digital wireless system
  • No interference, as operates outside of DTV or 3G bands
  • Automatic Frequency Selection. Plug & Play. Ease of use and reliability
  • Offers 3 levels of diversity (frequency, time and space) to ensure communication without interference
  • Rackable metal chassis, comes with a removable receiver (Kit setting rack included)
  • Supplied with 2 extractable receivers in the chassis, and two transmitters: a handheld microphone and bodypack transmitter
  • The possibility of 2 interchangeable receivers per chassis
  • Users can pair each receiver with up to 10 transmitters
  • 2 frames or 4 receivers can fit in a 19 '' 1U rack
  • Possibility to chain up to 5 frames (10 receivers) using RJ12 type cables (one cable per system)
  • Up to 10 systems can be used simultaneously without any frequency coordination problems or group selection
  • Hi-Fi audio quality over the whole frequency range (20 Hz to 20 kHz)
  • No compression during transmission and reception for clear, natural sound
Accessories Included Included AC adapter, Link cable, Rack-mount adapters, Joining plate, Rubber feet, AT8456a Quiet-Flex stand clamp
Audio Sampling 24 bit / 48 kHz
Battery Life 7 hours (alkaline) (Depending on battery type and use pattern)
Battery Type Two 1.5V AA
Dimensions ( Receiver ) 2.24" x 0.75" x 3.06" (Individual Unit), 8.26" x 1.73" x 6.67" (Chassis)
Dimensions ( Transmitter ) 2.76" x 4.21" 0.98"
Dynamic Range Less than 109 dB (A-weighted), typical
Frequency Response 20 Hz - 20 kHz Depending on microphone type
Harmonic Distortion More than 0.05% typical
Latency 3.8 ms
Manufacturer Part Number : ATW-1312
Operating Frequencies 2.4 GHz ISM band
Operating Range 60 m (200') Open range with no interfering signals
Operating Temperature Range 0°C to +40°C (32°F to 104°F)
Power Supply 100-240V AC (50/60 Hz) to 12V DC 0.5A power supply switched mode external
Receiver Weight 0.06 Kg
Transmitter Weight 0.09 Kg
