Are you looking for a powerful, yet affordable power amplifier? Look no further than the Phonic MAX 1500 Plus 900W Power Amplifier. With 900W of power at 8 ohms for bridge mono or 150W of power at 4 ohms for stereo inputs, this power amplifier is ideal for small to medium size spaces such as schools, churches, and studios.
FEATURES:
- Advanced powerful performance 3rd generation circuitry design
- Output power: 450W @ 4 ohms per channel, 280W @ 8 ohms per channel
- Front mounted gain controls
- High continuous current output from robust toroidal transformer
- Switchable input peak limiter and selectable high pass filter (30Hz, 50Hz) to reduce distortion and protect speakers
- Bridge mono and parallel mode LEDs
- Fast Recovery design for lower distortion if clipping occurs
- Very rugged housing
- Active balanced inputs for low noise
- Signal level at -40, -20, -10, protect and clip LED indicators to monitor performance
- Ground Lift switch to prevent humming
- Selectable stereo, parallel & bridge mono amp modes
- Two ventilation variable speed fans
- Speakon-type connectors and 5-way binding posts speaker outputs
- XLR & 1/4" TRS connectors for maximum input flexibility
- Requires two standard rack units for mounting
- Fits a standard 19" rack
SPECIFICATIONS:
| Product Line | Max |
| Manufacturer Part Number | MAX1500 |
| Product Name | MAX 1500 Plus Power Amplifier |
| Product Model | 1500 Plus |
| RMS Output Power | 450 W |
| Width | 482.8 |
| Depth | 415 mm |
| Weight Approximate | 14.60 kg |
| Height | 88.1 mm |
| Dimensions | 88.1 mm (H): 482.8 mm (W): 415 mm (D) |
| Impedance | 4 Ohm |
| Maximum Frequency Response | 1 kHz |
| Total Harmonic Distortion THD | 0.1% |
HOW IT WORKS:
1. Connect your audio source to the Phonic MAX 1500 Plus Power Amplifier using XLR and/or jack inputs.
2. Set the gain controls to the desired level.
3. Connect your speakers to the Speakon-type connectors or binding posts.
4. Switch the power on and adjust the volume to the desired level.
FAQ:
Q: What type of audio sources can be connected to the Phonic MAX 1500 Plus?
A: The Phonic MAX 1500 Plus Power Amplifier can be connected to audio sources with XLR and/or jack inputs.
Q: What type of speakers can be connected to the Phonic MAX 1500 Plus?
A: The Phonic MAX 1500 Plus Power Amplifier can be connected to speakers with Speakon-type connectors or binding posts.
Q: Does the Phonic MAX 1500 Plus have any protection features?
A: Yes, the Phonic MAX 1500 Plus Power Amplifier has short circuit, thermal, subsonic, RF protection, and output DC offset for maximum protection.
