Wharfedale Pro XC44N Digital System Controller with 4-in/4-out DSP, Dante Support
3,255.00 Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro XC44N Digital System Controller with 4-in/4-out DSP, Dante Support
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 813.75\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
KEY FEATURES
- 4 in – 4 out DSP control
- Compatibility with DP-F and DP-N amplifier platforms
- Comprehensive FIR preset library
- AES / EBU digital inputs with Link outs.
- Locking XLR input connectors
DESCRIPTION
The XC Series System Management controllers harvest the DSP engine capabilities of our successful DP-F and DP-N amplifiers to deliver both protection and enhanced definition to any system.
Equipped with an extensive loudspeaker preset library, FIR filters and advanced dynamics protection, the XC Series simply improves performance across all applications.
These 4 in – 4 out controllers are available with two interface options. XC-44F with Ethernet and XC-44N with Dante ™ connectivity. Both models are controlled with the Wharfedale Pro DSP Controller software where FIR presets for almost every Wharfedale Pro loudspeaker are available for free download. Both XC Series models feature AES / EBU input and analogue link outputs on Ch 1 and Ch 2.
SPECIFICATIONS
| Input / output | 4 x 4 |
| Input type | Analog, AES/EBU, Dante ™ |
| Input impedance | 20 kΩ（Balanced，10 kΩ（Unbalanced) |
| Output impedance | 600 Ω |
| Max input level | +20 dBu |
| Max output level | +20 dBu |
| THD+N | <0.02% (1 KHz,0 dB) |
| Frequency response | typical: +0, -1 dB (0 dB, 20 Hz-20 KHz) |
| Cross-talk | <-95 dB（1KHz） |
| SNR | >105 dB（A weighted） |
| Delay | <1.8 ms（Analog input/output，48 KHz） |
| Main power | 100-240 VAC ±10%, 50/60 Hz |
