KEY FEATURES
- Dual 15” subwoofer
- Stainless aluminium hardware
- Wax wrapped components
- Flattened front grille
- Single WY-24K4Z waterproof input connector
- WY-24K4Z Cable connector included
- 145 dB Max SPL @ 1 m
DESCRIPTION
Around the world, the WLA-28 and WLA-28X line array systems have become highly respected for sound quality, easy rigging and overall reliability. There is however a big ‘enemy’ for these systems. That enemy is…. H20…..water!
Introducing 3 new models in the WLA-28X family which overcome nature and give total peace of mind for outdoor installations and events! The all new F version (waterproof) WLA-28XF, WLA-28SUBXF and WLA-218BXF.
With reliability and high performance characteristics built from the ‘non-F’ models, these new XF models are IPX6 Certified. This certification states that there should be no harmful effects when “Water is projected in powerful jets (12.5mm nozzle) against the enclosure from any direction”
With rust-proof aluminium grilles, components wrapped in wax and anti-corrosion stainless steel screws and hardware, the F models are made for the rain and long-term environmental exposure.
SPECIFICATIONS
| Model Name | WLA-28SUBXF |
| System Type | Passive |
| Configuration | 2 x 15″ Subwoofer |
| Frequency Response (+/- 3dB) | 39-900 Hz |
| Frequency Range (- 10 dB) | 35-1.5 KHz |
| (Passive)Sensitivity 2.83v/1m | 108 dB |
| (Passive)Calculated Maximum SPL @1m | 145 dB |
| System Rated Impedance | 4 Ω |
| Low Frequency Transducer | |
| Size (mm / inches) | 381 mm / 15” |
| Voice Coil Size (mm / inches) | 100 mm / 4.0” |
| LF Magnet Material | ferrite |
| LF Frame Material | aluminium |
| Rated Impedance | 8 Ω x 2 |
| LF Power re:AES2-2012 | 600 W x 2 |
| High Frequency Transducer | |
| HF Driver Type: | – |
| Coil Size (mm / inches) | – |
| Exit Size (mm / inches) | – |
| HF Magnet Material | – |
| Diaphragm Material | – |
| Rated Impedance | – |
| HF Power re:AES2-2012 | – |
| Waveguide Type | – |
| Nominal Coverage (H x V) | – |
| System Continuous Power (w) | 1200 W |
| System Programme Power (w) | 2400 W |
| System Peak Power (w) | 4800 W |
| Crossover frequency | |
| Hardware | 1 x WY-24K4Z (waterproof) |
| Rigging | 4 points for rigging |
| pole mount | No |
| handles | Yes |
| cabinet type | square |
| Enclosure Material and finish | 18 mm plywood/3.0 mm Aluminium |
| Colour Options | Waterproof black paint |
| Grille Material & Finish | 3.0 mm Black Aluminium |
| Dimensions – Unpacked (mm / inches): | |
| Height front | 494 mm / 19.4″ |
| Height Rear | 494 mm / 19.4″ |
| Width | 845 mm / 33.3″ |
| Depth | 653 mm / 25.7″ |
| Dimensions – Packed (mm / inches): | |
| Height | 584mm / 23″ |
| Width Front | 933mm / 36.7″ |
| Width Rear | 933mm / 36.7″ |
| Depth | 723mm / 28.5″ |
| Weight | |
| Net Weight (kg / lbs) | 81.0kg / 178.2lbs |
| Gross Weight (kg / lbs) | 86.4kg / 190.1lbs |
