Wharfedale Pro WLA28A Line Array Active PA Speaker
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro WLA28A Line Array Active PA Speaker
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 1023.75\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
KEY FEATURES
- Dual 8″ active
- 132 dB Max SPL @ 1 meter
- 15 mm / 18 mm Birch plywood construction
- 100° x 10° dispersion
- 650 W LF + 100 W HF Continuous
- 1300 W LF + 200 W HF Peak
- 8 x DSP presets including FIR
DESCRIPTION
The quality and durability of the well established WLA series is now available in an active series. The series consists of 5 new models which are enhanced with internal DSP using FIR presets. Ethernet control also delivers remote system management tools through a single cable.
The line-up consists of a 2 x 8” array element, two active floor monitors, a dual 15” flown subwoofer and the 2000 W continuous WLA-218BA dual 18” subwoofer. A combination of products which allows for comprehensive systems to be designed, installed and toured.
The system is also compatible with the WLA-28 Common Fly Frame and WLA-28 Dolly Frame and can also be protected using the readily available WLA Series tourbags.
At the heart of the WLA-28A are 2 x 8″ custom Wharfedale Pro LF drivers.
These feature 2.0″ voice coils to ensure high efficiency and high power handling.
These perfectly matched custom transducers are what give a WLA-28A system that special sonic impact.
We recommend using SC48FIR DSP with the Line Array.
Bundle1: 4X WLA28A , 1X WLA28SUBA, WLA28FLYFRAME
Bundle2: 4X WLA28A , 1X WLA218SUBA, WLA28FLYFRAME
Bundle 3: 6 X WLA28A , 1X WLA218SUBA Bundle 4: 6 X WLA28A , 1X WLA28SUBA, WLA28FLYFRAME
SPECIFICATIONS
| Model Name | WLA-28A |
| System Type | Active 8” 2-way Bi-Amplified |
| Frequency Response (+/-3 dB) | 60 Hz – 20 KHz |
| Frequency Range (-10 dB) | 55 Hz – 20 KHz |
| Loudspeaker Sensitivity @ 1 W / 1 m) | 100 dB |
| Maximum SPL(peak)(@1 m) | 132 dB |
| Nominal Coverage (H x V) | 100° x 10° |
| Signal Processing | DSP based, 8 FIR presets resident in Input Module |
| Preset list | A) 1 SPKR 100 Hz HPF |
| B) 2 to 4 SPKR 100 Hz HPF | |
| C) 4 to 8 SPKR 100 Hz HPF | |
| D) >8 SPKR 100 Hz HPF | |
| E) 2 to 4 SPKR | |
| F) 4 to 8 SPKR | |
| G) >8 SPKR | |
| H) CUSTOM | |
| Amplifiers | |
| Amplifier Design | Class D |
| Power Rating: | 1500 W Peak (1300 W LF + |
| 200 W HF), 750 W Continuous | |
| (650 W LF + 100 W HF) | |
| Power On Protection | Power switch on/off mute |
| Thermal Protection | Amplifier Shut Down. Auto Reset |
| Low Line Voltage Shut Down | 80% Nominal Line Voltage |
| Driver Protection | Independent L/ H Limiters and DC |
| DC and Short Protection | Yes |
| Limiter Indicator | Red LED |
| Signal Indicator | Green LED |
| Power/Active Indicator | White LED |
| Find Function Indicator | Blue LED |
| Input Sensitivity | +4 dBu |
| Maximum Input Level | +18 dBu |
| Input Impedance | Balanced: 10 KΩ |
| AC Power details – Power Supply | High Efficiency Switching Mode Power Supply |
| Connectors | |
| Input Connector | XLR 1/ 4〞Combo jack |
| Link Connector | Balanced XLR pin Connector |
| UPDATE | USB Type B |
| NETWORK (RS485) | RJ45 |
| AC Power Options | AC 100-120 V~/ 220-240 V~,50/60 HZ |
| AC Input Connector | powerCON |
| AC Loop Through Connector | powerCON |
| Hardware – Rigging | Integral side plate adjustable |
| rigging 0°-10° | |
| Enclosure Material and finish | 15 mm / 18 mm Plywood |
| Colour Options | black paint |
| Grille Material & Finish | 1.5 Steel |
| Unpacked dimensions – Height | 250 mm / 9.84″ 181 mm / 7.1″ |
| Width (Front) | 760 mm / 29.92″ |
| Width (Back) | 760 mm / 29.92″ |
| Depth | 463.2 mm / 18.23″ |
| Packed Dimensions – Height | 320 mm / 12.6″ |
| Width (Front) | 830 mm / 32.7″ |
| Width (Back) | 830 mm / 32.7″ |
| Depth | 534 mm / 21.0″ |
| Net Weight (Kg / lbs) | 30.2 Kg / 66.4 lbs |
| Gross Weight (Kg / lbs) | 32.5 Kg / 71.5 lbs |
It is imperative to use the Wharefedale Pro SC48FIR DSP with any Wharfedale Pro WLA Series Line Array
