Wharfedale Pro WLA121SUB Line Array Subwoofer Passive 1x21" 1600W Continuous, 4Ω impedance
6,825.00 Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro WLA121SUB Line Array Subwoofer Passive 1x21" 1600W Continuous, 4Ω impedance
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 1706.25\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
Download Product Data Sheet
Note - It is imperative to use the Wharefedale Pro SC48FIR DSP with any Wharfedale Pro WLA Series Line Array. This is part of a system. We recommend contacting our sales team for a full system design.
FEATURES
- 21″ Beyma driver
- 1600 W Continuous
- 3200 W Programme
- 6400 W Peak
- 4.0″ Quattro LF voice coil (4 layers)
- 147 dB System Peak SPL
DESCRIPTION
The science behind the new WLA-1 Hybrid Curvature Array is intense.
With 12” and 15” full-range elements and a breath-taking 21” subwoofer, the new WLA-1 system has been engineered by IAG’s International R&D team to be highly versatile – making it perfect for touring and fixed installations.
The drivers inside are very special. Designed and Engineered by Wharfedale Pro UK and manufactured in Europe by Beyma, the full-range WLA-112 and WLA-115 elements use a coaxial design in combination with the exclusive incredible EVO-Fold high frequency waveguide. This design provides consistent dispersion coverage on both the horizontal and vertical planes with the sound radiating from one, singular and coherent, source. Together with the dedicated FIR presets library a flatter phase front is granted allowing outstanding audio quality performance.
This highly engineered solution combats issues that traditional constant curvature two way systems suffer from due to physical spacing between the drive units.
Meanwhile, the WLA-121SUB uses a 21” Beyma driver with a 4.0” Quattro voice coil which results in the most extreme, but controllable flying subwoofer in the Wharfedale Pro line up.
The WLA-1 system can easily be configured in 3 different ways. As a sub-top pole mount, as a flown array with the optional Common Fly Frame, or as a Horizontal system with the optional WLA-1 Link hardware. Such versatility allows for users to deploy the system for multiple activities.
SPECIFICATIONS
| Design | Subwoofer |
| System Type | 21″ Subwoofer |
| Configuration | Single Subwoofer |
| Frequency Response (+/-3 dB) | 25 Hz – 100Hz |
| Frequency Range (- 10 dB) | 18 Hz – 125 Hz |
| Sensitivity 2.83 V/1 m | 103 dB* |
| Calculated Maximum SPL @ 1 m | 141 dB* |
| System Peak SPL | 147 dB** |
| System Rated Impedance | 4 Ω |
|
|
100 Hz |
| Recommended HPF = BW 18 dB/oct. | 20 Hz |
| Input Connector | 2 x speakON compatible |
