Download Product Data Sheet
FEATURES
- 2 x 10″ LF drivers
- 3″ Neodymium HF compression driver
- 138 dB Max SPL
- 15mm / 18mm Birch plywood construction
- Integral, side plate adjustable rigging system
- 100° x 10° dispersion
- 180 watts programme HF
- 1600 watts programme LF
- 16 Ω impedance
DESCRIPTION
The WLA-210X line array system keeps the same design philosophies as the acclaimed WLA-25 and WLA-28 systems from Wharfedale Pro. Portable, powerful and versatile line array solutions which are ideal for both touring and fixed installation applications.
Each WLA-210X element uses a pair of custom 10” Wharfedale Pro high-power low-frequency drivers, while the high frequencies are handled by a premium 3.0” titanium diaphragm, neodymium magnet compression driver coupled to a 100° x 10° waveguide.
The waveguide exit extends nearly to the top and bottom of the enclosure to create a continuous acoustical source – resulting in greatly reduced destructive interaction within the array.
The WLA-210X element also features Passive and Bi-amp modes which allows for complete system control. The bi-amp feature enables the system designer to select the best amplification for each driver component within the array. Such control, when used with external signal processing such as the Wharfedale Pro Versadrive series, gives the engineer the ultimate in system fine tuning. This, in turn, leads to the best audio output.
SPECIFICATIONS
|
Model Name |
WLA-210X |
| System Type | Passive |
| Configuration | Two-way 2 x 10” |
| Frequency Response (+/-3 dB) | 65 Hz – 20 KHz |
| Frequency Range (-10 dB) | 60 Hz – 20 KHz |
| Sensitivity (2.83 v / 1 m) | 102 dB |
| Calculated Maximum SPL @1 m | LF:135 dB HF:138 dB |
| System Rated Impedance | 16 Ω |
| Low Frequency Transducer | |
| Size | 2 x 260 mm / 2 x 10” |
| Voice Coil Size | 65 mm / 2.5” |
| Rated Impedance | 8 Ω x 2 |
| LF Power (re:AES2-2012) | 2 x 400 W |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver – Neo |
| Voice Coil Size | 75 mm / 3.0” |
| Exit Size | 35.56 mm / 1.4” |
| Diaphragm Material | Titanium |
| Rated Impedance | 8 Ω |
| HF Power (re:AES2-2012) | 80 W |
| Nominal Coverage (H x V) | 100° x 10° |
| Power | |
| System Continuous Power | LF:800 W HF:90 W |
| System Programme Power | LF:1800 W HF:180 W |
| System Peak Power | LF:3600 W HF:360 W |
| Crossover frequency | 1.5 KHz |
| Input Connector | 2 x speakON compatible |
| Hardware | Integral side plate adjustable |
| rigging 0°-10° | |
| Enclosure | |
| Enclosure Material | 15 mm / 18 mm Plywood |
| Finish | Rhino Black Paint |
| Grille Material & Finish | 1.2 mm Black Steel |
| Dimensions – (Unpacked) | |
| Height Front | 314 mm / 12.4” |
| Height Rear | 240.2 mm / 9.46” |
| Width | 760 mm / 29.9” |
| Depth | 504 mm / 19.84” |
| Dimensions – (Packed) | |
| Height | 404 mm / 15.9” |
| Width Front | 855 mm / 33.7” |
| Width Rear | 855 mm / 33.7” |
| Depth | 594 mm / 23.4” |
| Weight | |
| Net Weight (kg / lbs) | 34.8 kg / 76.6 lbs |
| Gross Weight (kg / lbs) | 38.5 kg / 84.7 lbs |
HOW IT WORKS:
The WLA-210X Line Array System from Wharfedale Pro features both Passive and Bi-amp modes. The Passive mode allows the system to be powered by a single amplifier, while the Bi-amp mode enables the system designer to select the best amplification for each driver component within the array. This, in turn, gives the engineer the ultimate in system fine-tuning and leads to the best audio output.
It is imperative to use the Wharefedale Pro SC48FIR DSP with any Wharfedale Pro WLA Series Line Array
