Wharfedale Pro SIGMA-15 Passive PA Speaker (Discontinued)
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro SIGMA-15 Passive PA Speaker (Discontinued)
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 286.0\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
KEY FEATURES
- 350W RMS / 700W Program / 1400W Peak
- 129dB Max SPL
- 50Hz – 20kHz frequency response
- Discreet and unobtrusive design
- Newly developed angled corner port system to reduce dimensions
- Multiple M8 rigging points and a 35mm speaker pole mount for easy installation
- Crossovers tailored for vocal intelligibility
- Chip resistant Rhino Rock paint
- High performance HF driver with aluminium rear cover for maximum heat dissipation
- Double roll surround LF driver for stability and power
- 2.5” voice coil
DESCRIPTION
With its discreet and unobtrusive design SIGMA-15 features the latest proprietary Wharfedale Pro driver technology. In addition, SIGMA-15 uses a newly developed angled corner port system so that the dimensions have been reduced without compromising the overall sound quality. Available in black or white and with comprehensive rigging options SIGMA-15 and the new SIGMA SERIES is already a versatile and favourite choice for installers.
Wharfedale Pro engineers have matched the acoustic properties of the cabinet to the proprietary driver technology within, while taking physical aspects into consideration to ensure optimal positioning and size for installation.
By using a newly-developed angled-corner port system, cabinet height and overall size has been reduced – ideal for unobtrusive mounting within your venue. Additionally the angle-corner port system is fine-tuned acoustically to ensure low- end punch – just as you would expect with a larger PA speaker.
SPECIFICATIONS
| Model Name | SIGMA-15 |
| System Type | Passive |
| Configuration | Two-way |
| Frequency Response (+/-3dB) | 45Hz-18kHz |
| Frequency Range (-10 dB) | 50Hz-20kHz |
| Sensitivity (2.83v/1m) | 98dB |
| Calculated Maximum SPL @1m | 129dB |
| System Rated Impedance | 8Ω |
| Low Frequency Transducer | |
| Size | 381mm / 15” |
| Voice-Coil Size | 64mm / 2.5” |
| Rated Impedance | 8Ω |
| LF Power (re:AES2-2012) | 350W |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Voice-Coil Size | 44mm / 1.75” |
| Exit Size | 1″ |
| Diaphragm Material | Titanium |
| Rated Impedance | 8Ω |
| HF Power (re:AES2-2012) | 40W |
| Nominal Coverage (H x V) | 90° x 60° |
| Power | |
| System Continuous Power | 350W |
| System Programme Power | 700W |
| System Peak Power | 1400W |
| Crossover frequency | 2kHz |
| Input Connector | 2 x NL4 (speakON compatible) |
| Hardware | Dual-angle (0° or 10°) 35mm pole socket M8 x 5 2 handles on sides |
| Enclosure | |
| Enclosure Material | 15mm MDF |
| Finish | Black or white |
| Grille Material & Finish | 1.2mm steel, painted |
| Dimensions – Unpacked | |
| Height | 635mm / 25″ |
| Width Front | 435mm / 17″ |
| Width Rear | 261mm / 11.7″ |
| Depth | 439mm / 17.25″ |
| Dimensions – Packed | |
| Height | 720mm / 28.35″ |
| Width Front | 553mm / 21.75″ |
| Width Rear | 303mm / 12″ |
| Depth | 488mm / 19.2″ |
| Weight | |
| Net Weight | 23.4kg / 51.5lbs |
| Gross Weight | 26.7kg / 58.7lbs |
