Wharfedale Pro SC26X Versadrive Speaker Management System w/ 2 x XLR inputs and 6 x XLR outputs
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro SC26X Versadrive Speaker Management System w/ 2 x XLR inputs and 6 x XLR outputs
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 504.0\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
KEY FEATURES
- RMS Compressors and Peak Limiters.
- Dual band Dynamic EQ stage on Inputs.
- 96 KHz sampling frequency
- PC Software control
- USB, Ethernet and RS485
- Protect and survive!
DESCRIPTION
To maximise the performance of any PA system – but moreover to protect it – DSP is essential.
Introducing the entry level model in the Versadrive series of DSP processors from Wharfedale Pro – SC-26X.
SC-26X replaces the long-serving SC-26 and, although listed as an entry model, the new SC-26X brings several important and practical features to loudspeaker management.
All parameters of the Versadrive can be controlled via PC.
Not only is this extremely convenient, but a clear central graphical representation of your EQ and crossover points are displayed. This also makes light work of copying channel settings and organising your presets.
Using the PC software also allows for system backups to be made.
SPECIFICATIONS
| Model Name | Versadrive SC-26X |
|---|---|
| Inputs | 2 x XLR socket |
| Outputs | 6 x XLR pin |
| Input Impedance | Balanced : 20 KΩ |
| Output Impedance | Balanced : 100 KΩ |
| PC Port | USB (Front panel). Ethernet and RS485 (Rear panel) |
| CMRR | >70 dB (1 KHz) |
| Input range | ≤ +16.3 dBu |
| Frequency Response | 19.7 Hz – 20 KHz (+/- 0.5 dB) |
| SNR | >104 dB |
| THD | < 0.01% (Output = 0 dBu / 1 KHz) |
| Channel separation | > 100 dB (1 KHz) |
| Processor | 32-bit processor |
| AD / DA converter | 24-bit, 96 KHz sampling frequency |
| Display | 2 x 24 LCD backlight display. 5-band LED display. Mute / Editing status |
| Power consumption | ≤ 25 W |
| Power | AC 110 V / 220 V 50 / 60 Hz |
| Dimensions – Unpacked (W x D x H) | 482 mm x 190 mm x 44 mm |
| Net Weight | 3.6 Kg |
| Dimensions – Packed (W x D x H) | 562 mm x 296 mm x 98 mm |
| Gross Weight | 4.5 Kg |
