Wharfedale Pro GPL12 Speaker Passive 1x12" 1800W Peak 8Ohms Wooden Paint Body
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro GPL12 Speaker Passive 1x12" 1800W Peak 8Ohms Wooden Paint Body
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 787.5\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
KEY FEATURES
- 60° conical coverage
- 450 W AES (Continuous)
- 900 W Programme
- 1800 W Peak
- 4.0” LF Voice coil
- 131 dB Max SPL @ 1 m
DESCRIPTION
With a more natural and prominent sound than standard point source systems, Wharfedale Pro announce the GPL Series.
Compact cabinets and coaxial drive units make the GPL series perfect for theatre, enterprise, bars, nightclubs and live music applications. 12 new models, including bass-reflex and a band-pass subwoofer, available in either black or white finishes means that the GPL series is serious for fixed installation projects where audio quality matters.
A unique characteristic of the GPL series is that all full range models feature an original design waveguide horn. This allows the high frequency range to be addressed directly to the audience and reduces undesired reflections. The “HQ” models of the series are equipped with a turntable constant directivity horn for even more accurate asymmetrical coverage.
SPECIFICATIONS
| System Type | 12″ coaxial passive |
| Configuration | two-way |
| Frequency Response (+/-3 dB) | 55 Hz – 20 KHz |
| (DP-N preset) | |
| Frequency Range (- 10 dB) | 35 Hz – 25 KHz |
| (DP-N preset) | |
| Sensitivity 2.83 V/1 m | 98 |
| Sensitivity 2.83 V/1 m half space | / |
| Calculated Maximum SPL @1 m | 131 dB |
| System Peak SPL* | 137 dB |
| *level at 1 m using pink noise with crest factor 4, with dedicated preset. | |
| System Rated Impedance | 8 Ω |
| Low Frequency Transducer | |
| Size | 312 mm / 12” |
| Voice coil size | 101.6 mm / 4.0” |
| LF Frame Material | Aluminium |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Coil Size (mm / inches) | 72.2 mm / 2.87″ |
| Exit Size (mm / inches) | 38.1 / 1.5″ |
| Diaphragm Material | Composite titanium / polyester |
| Waveguide Type | Spherical |
| Nominal Coverage (H x V) | 60° conical |
|
|
|
