Wharfedale Pro EVP-X12M MKII Speaker Monitor Passive 1x12" 300W RMS 8Ohm Wooden Carpet Body
693.00 Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Wharfedale Pro EVP-X12M MKII Speaker Monitor Passive 1x12" 300W RMS 8Ohm Wooden Carpet Body
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 173.25\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
Download Product Data Sheet
Note -
KEY FEATURES
- 12″ floor monitor
- 1.75″ IRIS X HF driver
- 12″ LF driver with 2.5″ voice coil
- 300 watts AES (RMS)
- 600 watts Programme
- 1200 watts Peak
- 129 dB Max SPL @ 1 meter
DESCRIPTION
Each EVP-X MKII PA speaker and subwoofer is protected by a durable carpet covering and steel grille.
The MKII version features a 4-way carry handle and a dual angle pole mount making it both portable and versatile for varying installation applications, ensuring the HF sound is directed straight at your audience.
Full range models feature a 90° x 60° Elliptical Waveguide
In real-world terms this means that the higher frequencies can be heard with definition at 90° in the horizontal plane, and 60° in the vertical.
All full range models in the EVP-X MKII series use this same elliptical waveguide design which makes for controllable coverage when using multiple EVO-X series loudspeakers.
SPECIFICATIONS
|
Model Name
|
EVO-X12M |
| System Type | Passive |
| Configuration | Two-way Monitor |
| Frequency Response (+/-3 dB) | 60 Hz – 20 KHz |
| Frequency Range (-10 dB) | 55 Hz – 20 KHz |
| Sensitivity (2.83 v / 1 m) | 98 dB |
| Calculated Maximum SPL @1 m | 129 dB |
| System Rated Impedance | 8 Ω |
| Low Frequency Transducer | |
| Size | 305 mm / 12″ |
| Voice Coil Size | 51.6 mm / 2″ |
| Rated Impedance | 8 Ω |
| LF Power (re:AES2-2012) | 300 w |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Voice Coil Size | 44.5 mm / 1.75″ |
| Exit Size | 25 mm / 1″ |
| Diaphragm Material | Titanium |
| Rated Impedance | 8 Ω |
| HF Power (re:AES2-2012) | 40 w |
| Nominal Coverage (H x V) | 90° x 60° |
| Power | |
| System Continuous Power | 300 w |
| System Programme Power | 600 w |
| System Peak Power | 1200 w |
| Crossover frequency | 2.4 KHz |
| Input Connector | 2 x NL4 (speakON Compatible) |
| + 2 x 1/4″ Jacks | |
| Hardware | |
| Pole Mount | |
| Handles | 2 on Sides |
| Enclosure | |
| Enclosure Material | MDF |
| Finish | Rhino rock black paint |
| Grille Material & Finish | 1.2 mm Steel |
| Dimensions – Unpacked | |
| Height | 560 mm / 22.05″ |
| Width Front | 424 mm / 16.69″ |
| Width Rear | 424 mm / 16.69″ |
| Depth | 441 mm / 17.36″ |
| Dimensions – Packed | |
| Height | 480 mm / 18.9″ |
| Width Front | 616 mm / 24.25″ |
| Width Rear | 616 mm / 24.25″ |
| Depth | 490 mm / 19.29″ |
| Weight | |
| Net Weight (kg / lbs) | 18.1 kg / 39.8 lbs |
| Gross Weight (kg / lbs) | 21.5 kg / 47.3 lbs |
