Turbosound TS-15W300/8A 300W 15" Low-Frequency Loudspeaker for PA Applications
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Turbosound TS-15W300/8A 300W 15" Low-Frequency Loudspeaker for PA Applications
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 117.25\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
SPECIFICATIONS
General Specifications
Loudspeaker diameter |
394 mm / 15" |
Impedance |
8 Ω |
Continuous power rating1 |
300 W |
Peak power rating2 |
1200 W |
Sensitivity |
97 dB (±2.5 dB, 1 W / 1 m) |
Frequency range |
Fo ~3 kHz (-10 dB) |
Magnet size |
190 mm |
Voice coil diameter |
75.5 mm / 3" |
Bobbin material |
Glass fiber SV |
Wire type |
Copper wire |
Winding height |
17.8 mm |
Layers |
2 |
Cone body |
Paper |
Cone surround |
Cloth |
Item part number |
H77-00002-31677 |
Thiele & Small Parameters
Resonance frequency (Fs) |
46 Hz |
DC resistance (Re) |
6.5 Ω |
Mechanical Q factor (Qms) |
16.6 |
Electrical Q factor (Qes) |
0.49 |
Total Q factor (Qts) |
0.47 |
Mechanical moving mass (Mms) |
96.4 g |
Mechanical compliance (Cms) |
0.12 mm/N |
Force factor (Bl) |
19.3 |
Equivalent acoustic volume (Vas) |
130.2 I |
Maximum linear displacement (Xmax) |
4.9 mm |
Diaphragm area (Sd) |
865.7 sq cm |
Voice coil inductance @ 1 kHz (Le) |
1.2 mH |
Shipping Information
Net weight | 7.1 kg (15.6 lbs) |
Shipping weight | 10 kg (22 lbs) |
