Turbosound TS-10W300/8A 300W 10" Low-Frequency Loudspeaker for PA Applications
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Turbosound TS-10W300/8A 300W 10" Low-Frequency Loudspeaker for PA Applications
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 87.25\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
KEY FEATURES-
10" high-power woofer for PA applications
-
Continuous power: 300 Watts RMS
-
Maximum power: 1,200 Watts Peak
-
Impedance: 8 Ohms
-
Frequency range: 53 Hz - 4 kHz
-
SPL: 93 dB (1 W / 1 m)
-
Rigid aluminum die-cast frame
-
Mounting hole diameter: 245 mm (9.65")
-
Shipment Weight: 5.1kg (11.2lbs.) and Net Weight :4.5kg (9.9lbs.)
-
Overall diameter: 261 mm (10.28")
DESCRIPTION
Powerful PA speaker systems call for Turbosound drivers, which are designed to bring out the best audio performance no matter the genre or application. The 10” TS-10W300/8A low frequency driver provides tight and punchy bass performance and handles up to 1,200 Watts of peak output (300 Watts RMS), with a frequency range that extends from 53 Hz to 4 kHz. The die-cast aluminium frame is extremely rigid and light in weight, making it ideal for use as a replacement driver – or for deployment in custom-engineered multi-way PA enclosures.
SPECIFICATIONS
General Specification
Loudspeaker diameter: 261 mm / 10"
Impedance: 8 Ω
Continuous power rating: 300 W
Peak power rating: 1200 W
Sensitivity: 93 dB (±3 dB, 1 W / 1 m)
Frequency range: Fo ~4 kHz (-10 dB)
Magnet size: 156 mm
Voice coil diameter: 65.5 mm / 2.5"
Bobbin material: Glass fiber SV
Wire type: PISV wire
Winding: height 17 mm
Layers: 2
Cone body: Paper
Cone surround: Cloth
Item part number: H77-00002-31669
Thiele & Small Parameters
Resonance frequency (Fs): 53 Hz
DC resistance (Re): 7.8 Ω
Mechanical Q factor (Qms): 7.45
Electrical Q factor (Qes): 0.44
Total Q factor (Qts): 0.41
Mechanical moving mass (Mms): 47.8 g
Mechanical compliance (Cms): 0.19 Mm/N
Force factor (Bl): 16.9
Equivalent acoustic volume (Vas): 31.6 I
Maximum linear displacement (Xmax): 3.4 Mm
Diaphragm area (Sd): 346 Sq cm
Voice coil inductance @ 1 kHz (Le): 0.8 mH
Shipping Information
Net weight: 4.5 kg / 9.9 lbs
Shipping weight: 5.1 kg (11.2 lbs)
