The G Sub 1501 DP+ is a universal 15 ”high-performance subwoofer in a particularly flat design with two-channel amplifier electronics and DSP controller. Four practical presets and volume adjustments can be called up to adapt to the application.
With a basic size of 60 x 60 cm, it can also tilt larger HiMid systems in bar operation and can be easily integrated into existing stage constructions with a height of only 40 cm.
It convinces with its good handling and its deep and rich bass foundation.
|Speaker Components||15“ Nd|
|Description||Passive Bass Extension|
|Power AES / Peak||1000 W / 3000 W|
|Impedance||nominal 8 Ω|
|SPL||1 W / Peak @ 1 m|
|100 dB / 135 dB|
|35 Hz - 220 Hz (- 6 dB)|
|Tuning Frequency Excursion minimum||42 Hz|
|Connectors||2 x Neutrik Speakon NL4MP in/out|
|Coding:||1 +/- loop thru, 2 +/- Sub|
|Incl. switcher for active / passive operation|
|Rigging / Fittings||M20 on top|
|Weight 26,0 kg||(+ 6,0 kg wheelboard)|
|Size height x width x depth||40,0 x 60,0 x 60,0 cm|
