Midas

SKU: L10

Midas L10 00 Series Rackmount Chassis for 10 Modules with Advanced Audio Routing

Dhs. 1,279.00

Did You Find a Better Price?

On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.

Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.

Please note: we only match product prices vs other UAE websites.
Sold out

Pre-Booking

Midas L10 00 Series Rackmount Chassis for 10 Modules with Advanced Audio Routing - L10

Talk to a Pro

Speak to our Music & Audio Pros

The quickest way to get some info

+971558907585

Chat with our Pros on Whatsapp

We're available from Monday to Saturday (9.30am-6.30pm GST)
×

Midas L10 00 Series Rackmount Chassis for 10 Modules with Advanced Audio Routing

MM HO

Pickup currently unavailable

Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates

+971558907585

MM Market

Pickup currently unavailable

Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates

+971558907585

MM Warehouse

Pickup currently unavailable

Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates

+971558907585
Connect On WhatsApp +971558907585

Pay as low as Dhs. 319.75\/mo. without fees with Tabby.

Free & Express Shipping in UAE Available.

Authorized Midas Retailer

Midas - MusicMajlis
Earn Dhs. 1,279 MM Notes 🎶 when you sign in and order

Notify me when this product is available:

Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information

KEY FEATURES

  • 500 series rackmount chassis for 10 single-width modules

  • Advanced audio routing reduces cabling complexity

  • Audio output link switches provide cable-free daisy-chain connections between modules

  • Compressor bus link switches enable stereo and multi-channel dynamics sidechain linking

  • Rugged 3U rackmount chassis for durability in portable applications

  • Earth lift switch eliminates any ground loop problems

  • High power auto-ranging universal switch-mode power supply for use worldwide

  • Over-specified ultra-low noise power supply output provides 3.2 A @ ±16 V and 300 mA @ +48 V

  • Main and auxiliary inputs and outputs per channel on Neutrik* XLR connectors

  • Premium quality components throughout for crystal-clear audiophile signal path


DESCRIPTION

The LEGEND L10 500 Series Rackmount Chassis lets you mix and match a wide range of audio processing modules to build the ideal signal chain for any application. With space for up to 10 single-width modules, advanced audio routing for simplified cabling, and a robust auto-ranging universal switch-mode power supply, you can take your favourite modules anywhere in the world with complete confidence. Designed to accommodate all 500 series-compatible modules and plug-in cards, the L10 is the perfect companion for your MICROPHONE PREAMPLIFIER 502, COMPRESSOR LIMITER 522, PARAMETRIC EQUALISER 512, and the many other modules currently under development – as well as those from 3rd party vendors.

SPECIFICATIONS

Controls

Power

Front panel switch and lamp

Comp Bus

Rear panel switches,1-2, 2-3, 3-4, 4-5, 5-6, 6-7, 7-8, 8-9, 9-10

Audio link

Rear panel switches,1-2, 2-3, 3-4, 4-5, 5-6, 6-7, 7-8, 8-9, 9-10

Ground lift

Rear panel switch

Input and Output

Input

10 x balanced XLR

Aux input

10 x balanced XLR

Output

10 x balanced XLR

Aux output

10 x balanced XLR

Power Requirements

AC Input Voltage

100-240 VAC, 50-60 Hz, IEC input

Output Voltages

3.2 A @ ±16 V, 300 mA @ +48 V (phantom power)

Power consumption

Typically 55 W

Physical

Dimensions (HxWxD)

140 x 483 x 211 mm (5.5 x 19 x 8.3")

Dimensions (HxWxD) without feet

132 x 483 x 211 mm (5.2 x 19 x 8.3")

Weight

4.9 kg (10.8 lbs)
