Behringer XENYX 502S Premium Analog 5-Input Mixer with USB Streaming Interface
260.00
Regular price 310.00 Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
Did You Find a Better Price?
On of our goals is to ensure that we deliver the best value possible to MusicMajlis customers.
Authorized dealers that are selling genuine music instruments and audio equipment in the GCC are required to comply with Minimum Advertised Price (MAP) policies as set by the manufacturers.
Please note: we only match product prices vs other UAE websites.
50.00 Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Behringer XENYX 502S Premium Analog 5-Input Mixer with USB Streaming Interface
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Market
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 65.0\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
KEY FEATURES
-
Ultra-low noise analog mixer for streaming, podcasting and recording
-
Award winning XENYX microphone preamp for warm and musical sound
-
Stereo USB audio interface to connect to your computer or mobile device
-
Direct mixing of PC/gaming sounds into the streaming output
-
Analog mixing and equalization for pure sound
-
Versatile sub mixer for network enabled audio devices
-
Stereo channel 4/5 automatically switches between TRS input and USB playback
-
High-quality main, phones and streaming outputs
-
Stereo RCA inputs assignable to main mix or monitor/phones outputs
DESCRIPTION
XENYX 502S
The ultra-compact XENYX 502S mixer’s 5 inputs allow you to effortlessly achieve premium-quality sound that’s perfect for streaming, podcasting and recording. It provides a warm and ultra-musical sound thanks to its award-winning XENYX microphone preamp.
Great for Any Setup
The new XENYX “S” series can be connected to computers or mobile devices via USB making it super easy to integrate digital sources with analog equipment. One mono and 2 stereo channels allow you to mix up to 5 signals, blending them to a stereo RCA streaming input and a stereo USB input. That is a total of 9 crystal-clear audio signals for monitoring via headphones or the high-quality TRS Main outputs. The 502S can also be used as a versatile sub mixer for combining network enabled audio devices with other analog signals.
Amazing Gear at an Affordable Price
The XENYX 502S is a great partner for any dynamic microphone, upgrading your streaming, podcasting or recording setup with a decent microphone input, while simultaneously providing simple, super-convenient control at your fingertips.
Get the XENYX 502S from your local Behringer dealer today!
SPECIFICATIONS
| Section | Parameter | Specification |
|---|---|---|
| Mono Inputs | Microphone Input | Balanced XLR, discrete input circuit |
| Mic EIN (22 Hz–22 kHz) @ 50 Ω | 132 dB, A-weighted | |
| Frequency Response @ +10 dB Gain | 10 Hz to 150 kHz | |
| Frequency Response @ +60 dB Gain | 20 Hz to 70 kHz | |
| Gain Range | +10 dB to +60 dB | |
| Max Input Level @ +10 dB Gain | +12 dBu | |
| Input Impedance | 2 kΩ balanced | |
| Distortion (THD + N) @ 1 kHz, +10 dB Gain | 0.005% | |
| Mono Line Inputs | Connector | 1/4" TRS balanced |
| Impedance | 22 kΩ balanced, 10 kΩ unbalanced | |
| Gain Range | -10 dB to +40 dB | |
| Max Input Level @ 0 dB Gain | +21 dBu | |
| Stereo Inputs | Stereo Line Connector | 1/4" TRS balanced |
| Frequency Response | 20 Hz to 200 kHz | |
| Impedance | 22 kΩ balanced, 10 kΩ unbalanced | |
| Max Input Level @ 0 dB Gain | +21 dBu | |
| STREAM Inputs (Analog) | RCA connector unbalanced | |
| STREAM Input Impedance | 10 kΩ unbalanced | |
| STREAM Max Input Level | 10 dBu | |
| Equalizer | Low EQ | 80 Hz / ±15 dB |
| High EQ | 12 kHz / ±15 dB | |
| Main, Monitor & FX Outputs | Type | 1/4" TRS impedance-balanced |
| Impedance | 120 Ω | |
| Max Output Level | 21 dBu | |
| Phones Out | Type | 1/4" TRS unbalanced |
| Impedance | 23 Ω | |
| Max Output Level | 19 dBu / 150 Ω | |
| STREAM Out (Analog) | Type | RCA connector unbalanced |
| Impedance | 1 kΩ unbalanced | |
| Max Output Level | 10 dBu | |
| Main Mix Noise | Main Mix @ -∞ | -109 dBu A-weighted |
| Channel @ -∞ | -109 dBu A-weighted | |
| USB | Type | Type-B connector |
| USB Audio Data | 48 kHz / 16-bit | |
| UAC2 Class Compliant | Stereo in/out | |
| Power Supply | Power Consumption | 8 W |
| Adaptor Input | 100–240 V~, 50/60 Hz, 0.5 A | |
| Adaptor Output | 18 V DC, 1.0 A |
