Features-

• Analog polyphonic synthesizer and authentic reproduction of classic OB-Xa including original factory patches

• Vintage mode allows selection of 8 synthesizer signatures including OB-Xa, OB-8 and more

• 16 voices with 2 VCOs per voice and oscillator sync mode

• Multi-timbral capability allows splitting or layering 2 different sounds

• VCOs and VCFs based on reproductions of original 3340 and 3320 semi conductor designs

• Both VCOs generate sawtooth, triangle or square waveforms with variable pulse width

• Selectable dual-slope 12/24 dB analog low-pass filter per voice with adjustable resonance

• 61 semi-weighted full-size keys featuring poly after-touch and velocity sensitivity

• Flexible 8-channel modulation matrix for dramatic expansion of sonic possibilities

• Dual-layer arpeggiator and sequencer with real-time sequence transpose

• Velocity and after-touch can be optionally used for more expressive performance

• 2 dedicated LFOs with 7 waveform shapes for modulation of pulse width, oscillator pitch and filter cutoff frequency

• 2 ADSR generators per voice for control of VCF and VCA

• Stereo VCA per voice to allow control over voice/layer panning

• 26 rotary controls give direct and real-time access to all important parameters

• High-quality LCD Display with encoder for rapid parameter editing

• Assignable preset recall switches for immediate program selection

• Spring-loaded pitch and assignable modulation paddles provide total hands-on performance

• 512 user program memories with “compare and match” feature to quickly match all analog controls to stored program values

• Fully servo-balanced outputs for highest signal integrity

• CV/pedal inputs for connection to expression pedals and footswitches

• MIDI Polyphonic Expression (MPE) to enable multidimensional controllers and multiple parameters per note

• Comprehensive MIDI implementation (including NRPN/CC control of all parameters and bulk load/save)
