FEATURES

• 2 x 1,000 Watts into 4 Ohms; 2 x 600 Watts into 8 Ohms

• ATR (Accelerated Transient Response) technology for ultimate punch and clarity

• Ultra-light, ultra-low noise and ultra-efficient switch-mode power supply for noise-free audio, superior transient response and low power consumption

• Switchable limiters offer maximum output level with reliable overload protection

• Detented gain controls for precise setting and matching of sensitivity

• Precise Power, Signal and Limit LEDs to monitor performance

• XLR, 1/4" TRS and RCA input connectors for compatibility with any source

• Professional speaker connectors and "touch-proof" binding posts support most speaker wiring systems

• Built-in Subwoofer/Satellite crossover for more flexibility

• Independent DC and thermal overload protection on each channel automatically protects amplifier and speakers without shutting down the show

• "Back-to-front" ventilation system including air filter for reliable operation

• "Built-like-a-tank", impact-resistant and all-steel 2U rackmount chassis

• Minimum depth chassis (10.1" / 257 mm) and ultra-light weight design (15.4 lbs / 7.0 kg), fits into compact, inexpensive effects racks

DESCRIPTION

The remarkable EPQ2000 packs a heart-stopping 2,000 Watts of output power into an exceptionally lightweight (15.4 lbs/7.0 kg) package, thanks to our Accelerated Transient Response (ATR) technology. Ample power (2 x 1,000 Watts @ 4 Ohms; 2 x 600 Watts @ 8 Ohms) and high-tech efficiency combine, giving you a feather-light, supercharged workhorse that will keep your rig kicking for years and years to come.

Accelerated Transient Response Delivers the Knockout Punch
It takes huge pulses of energy (current and voltage) to propel a woofer cone out fast enough to match a bass beat. That’s called Transient Response and it’s the holy grail of amp design. By carefully selecting transistors with extremely high slew rates and optimizing other proprietary parts of our circuitry, our amps are able to react instantly to even the most demanding electronic bass impulses. If the woofers in your PA system can keep up, your audience will hear a tighter, crisper, more natural sound. Instead of operating relatively continuously like most power amps, the EPQ2000 features rail tracking for effectively modulating the power supply rails with only the peaks of the input signal. This technology has revolutionized pro audio amp designs with its outstanding performance and efficiency. When combined with switching-mode power supplies that do away with heavy toroid transformers, our new designs provide more dynamic punch and, since they are so much more efficient, run cooler and don’t require huge, heavy heat sinks.

SPECIFICATIONS
