KEY FEATURES
- Classic dual phase shifter for keyboards, guitar, drum machines and other sound sources
- Authentic recreation of the popular phase shifter from the ‘70s
- 12 opto-couplers for deep and natural phasing effects
- 2 independent phasors with Depth and Feedback controls
- 2 independent sweep generators with Rate and Shape controls
- Input selector combines both phasors for creative sound effects
- Sweep and Sync controls allow for a wide selection of modulation sources
- CV input for easy remote control with external devices
- Dual footswitch with true-bypass function for ultimate signal integrity
- Rugged and reliable metal construction
- Runs on Behringer PSU-SB DC power supply (not included)
DESCRIPTION
The DUAL-PHASE is an authentic recreation of the popular phase shifter from the '70s. It features 2 phase shifters, each with their own RATE, DEPTH and FEEDBACK controls, that you can then run in series or parallel. Each phase shifter also allows you to switch the wave shape oscillator between sine and square wave. The DUAL-PHASE brings all the amazing features from the original ‘70s design, plus a few modern ones, that are sure to enhance your pedal board or synth setup.
SPECIFICATIONS
| Input A / B |
2 x 1/4" TS jacks, unbalanced Impedance: 30 kΩ , unbalanced Maximum input level: +20 dBu |
| Output A / B |
2 x 1/4" TS jacks, unbalanced Impedance: < 470 Ω, unbalanced Maximum output level: +19.5 dBu |
| CV IN |
1 x 1/4" TRS jack, 1 V/oct CV input range: 0 V to +5 V |
| Sweep generator 1 / 2 |
Rate: 2 x rotary knobs Control range: 0.1 Hz to 18 Hz, adjustable Shape: 2 x rocker switch Sine / square wave, switchable |
| Phasor A |
Sweep: 1 x rocker switch Sweep generator 1 / control voltage, switchable Depth: 1 x rotary knob Feedback: 1 x rotary knob |
| Phasor B |
Sweep sync: 1 x rocker switch Normal / reverse phase, switchable Sweep: 1 x rotary switch Sweep generator 1 / generator 2 / control voltage, switchable Depth: 1 x rotary knob Feedback: 1 x rotary knob |
| Power supply |
External adapter |
| Power input |
Standard 9 – 12 V DC, center negative, > 700 mA |
| Power consumption |
6 W |
| Dimensions (H x W x D) |
62.9 x 200 x 174.6 mm (2.48 x 7.87 x 6.87") |
| Weight |
1.2 kg (2.7 lbs) |
