Behringer DI4800A Professional 4-Channel Active DI Box, Booster and Line Isolator
Talk to a Pro
Chat with our Pros on Whatsapp
We're available from Monday to Saturday (9.30am-6.30pm GST)
Behringer DI4800A Professional 4-Channel Active DI Box, Booster and Line Isolator
MM HO
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
MM Warehouse
Al Shoala Building, Near Deira City Center, Port Saeed Area
Techniline Electronics Showroom, Ground Floor, Block E
Dubai DU
United Arab Emirates
Pay as low as Dhs. 126.5\/mo. without fees with Tabby.
Free & Express Shipping in UAE Available.
Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
KEY FEATURES-
Professional and multi-purpose 4-channel direct injection box for stage and studio applications
-
Provides impedance and signal matching for the direct connection of instruments to mixers and amplifiers
-
Ultra-flat frequency response due to renowned Behringer OT-1 transformers
-
Total of +18 dB gain boost in three +6 dB increments for pre-amplification of low-level signals
-
Ground Lift switch eliminates typical ground loop problems
-
Switchable -20 dB output attenuation
-
Neutrik* combo and gold-plated XLR connectors
-
Powered via external DC power supply (included) with optional battery powered operation (sold separately)
DESCRIPTION
THE ULTRA-DI PRO DI4800A gives you 4 first-class DI channels in a single rack space. Each channel is equipped with one input (XLR or ¼” TRS) and two XLR Outputs at the front and back to connect to your amp or monitor console allowing for 8 outputs in all. Plus, the DI4800A is designed to accommodate virtually any input signal, with a switchable output attenuation of -20 dB, while our highly acclaimed OT-1 output transformers ensure pristine and powerful output.
SPECIFICATIONS
Inputs
|
Connectors |
4 x XLR-1/4" combo jacks, balanced |
|
Impedance |
20 kΩ |
|
Max. input level |
+20 dBu |
|
Channel boost switchable |
+6 dB,+12 dB,+18 dB |
Outputs
|
Connectors |
8 x XLR, transformer balanced |
|
Impedance |
600 Ω |
|
Max. output level |
+20 dBu |
|
Output pad switch |
20 dB attenuation |
System
|
Frequency response |
20 Hz to 20 kHz (±3 dB) |
|
THD + N (distortion) |
0.01% @ 1 kHz, 0 dBu |
|
Signal-to-noise ratio |
120 dB |
|
Ground lift switch |
Removes ground connection |
|
Power requirement |
12 V DC, 500 mA |
Physical
| Standard operating temperature range | 5° C – 40° C (41° F – 104° F) |
| Dimensions (W x D x H) | 483 x 71 x 44 mm(19.0 x 2.8 x 1.7"") |
| Weight | 1.4 kg (3.1 lbs) |
