Behringer

DEQ1024

Behringer DEQ1024 Graphic Equalizer

Delivery, Warranty & Returns Information

Beautifully sculpted, feedback-free sound can be yours, when the ULTRAGRAPH DIGITAL DEQ1024 has a place in your rack. It’s a 31-band equalizer, a Feedback Destroyer and Dynamics processor – all in one. Most importantly, state-of-the-art 24/48- bit DSP and ultra high-resolution 24-bit/96 kHz A/D - D/A converters deliver the ultimate in sonic resolution.

Features

  • Ultra-high resolution 24-bit/96 kHz processor featuring EQ, RTA and dynamic processing for PA and mastering applications
  • Unique "True Curve" Function—fader settings reflect actual frequency response
  • Revolutionary FBQ detection system instantly reveals critical frequencies and can also be used as Audio Analyzer
  • Automatic and ultra-fast Feedback Destroyer plus feedback indication via fader LEDs
  • "Inaudible" Noise Gate/Peak Limiter function plus amazing Stereo Imager for spatial enhancement

Tech Specs

Filter Type Graphic
Number of Channels 2
Inputs 2 x XLR (analog) 1 x XLR AES/EBU 1 x RCA coaxial S/PDIF
Outputs 2 x XLR (analog) 1 x XLR AES/EBU 1 x RCA coaxial S/PDIF
Maximum Input Level +12dBu or +22dBu, switchable
Frequency Bands 31 x 2, ISO spacing
Bandwidth 1/3 octave
Range (Boost/Cut) +/-6dB, +/-12dB or 0/-24dB, switchable
Maximum Output Level +12dBu or +22dBu, switchable
Frequency Response 15Hz to 35kHz, +/-3dB
Dynamic Range Not specified by manufacturer
Noisew SNR: 104dBu, A-weighted (22Hz to 22kHz)
Dimensions (WxDxH) 19" x 5 5/16" x 3 1/2"
Weight 5 lbs (shipping)
