DESCRIPTION

Your Man on the Inside
Is there a little tiny sound technician inside? Almost. If this were just a “dumb” powered loudspeaker, it would be one of the best you’ve ever heard. But we added smart digital processing that constantly adjusts the B412DSP’s sound as the music changes. It doesn’t matter whether you need a PA system for a heavy metal band, a church or a one-man show, you need a speaker that sounds as great at a whisper as it does when run full-out. The B412DSP is designed to handle a wide range of applications, with power to spare and the kind of fidelity typically only available from state-of-the-art studio monitors.

Digital processing is the audible B412DSP difference.
Lots of companies make “powered” speaker systems by simply strapping amps on the back of a conventional two-way speaker. They sound better than passive speakers. But they’re not taking advantage of 2008 digital technology. Until now, the few active systems that did use an internal digital “brain” for creating optimized sound were prohibitively expensive. Now the EUROLIVE B412DSP offers an intelligent solution at a price point that is unheard of in its class. The technology used in its design represents a major advancement in loudspeaker manufacture and performance.
How so?
First, digital eliminates the variables that result from conventional analog electronics: parts tolerances, changes in performance as the parts age, hard-to-solve audio problems such as phase linearity and crossover slopes. These variables literally make it impossible to consistently produce identical performance in every speaker — or the same speaker over its lifespan.
Second, digital vastly expands the signal processing capabilities that would require racks and racks of external analog equipment to achieve with a “dumb” active speaker.

A Pristine 24-bit/48kHz Digital Signal Path
From the instant the analog signal enters the B412DSP, the 24-bit digital processor takes over, ensuring the highest possible signal integrity — and we’re talking CLEAN. First, this internal computer does chores like assigning frequencies to the low and high frequency amplifiers far more elegantly and with less distortion than old analog crossovers ever could. Then it compensates for the inevitable non-linearities in transducer frequency response.
But much more than just selective EQ enhancement, the engine in the B412DSP analyzes the signal and intelligently applies specific filters to actually improve the sound quality depending on the bass content of the music and how loud you have it turned up. It’s like having a tiny sound guy inside each enclosure (with all the best gear), monitoring the input and output signals, dialing in the perfect EQ and constantly making subtle adjustments to the crossover, compressor/limiter and more.
This powerful 24-bit DSP circuitry takes all the guesswork out of running the system so you can concentrate on your performance. All these intelligent processes work together proactively behind-the-scenes, making the B412DSP the best-sounding 12" loudspeaker system on the market.

FEATURES

• High-power 600-watt 2-way PA sound reinforcement speaker with integrated
• Mixer for live and playback applications
• State-of-the-art 24-bit digital signal processor for ultimate system control
• Digital crossover, phase and time correction for perfect driver alignment plus dual compressor/limiter for total system protection
• Digital noise gate, low-cut filter, 2-band EQ, dynamic contour filter for ultimate sound reproduction
• 2 ULN Mic/line inputs with individual volume controls and peak LEDs
• Extremely powerful 12" long-excursion driver provides incredibly deep bass and acoustic power
• State-of-the-art 1.75" titanium diaphragm compression driver for exceptional high-frequency reproduction
• Ultra-wide dispersion and large-format exponential/conical horn wit multi-cell aperture throat
• Additional line output enables linking of additional speaker systems
• Versatile trapezoidal enclosure design allows different positioning stand mounting with 35-mm pole socket
• Tilts on its side for use as a floor monitor
• Ergonomically shaped handles for easy carrying and setup
