Note - It is imperative to use the Wharefedale Pro SC48FIR DSP with any Wharfedale Pro WLA Series Line Array. This is part of a system. We recommend contacting our sales team for a full system design.
KEY FEATURES
- 21” Subwoofer with 4.0” Quattro voice coil from Beyma
- EVO-Fold waveguide
- Integral side plate rigging
- Premium Baltic birch construction
- EASE .gll files for download
- FIR presets for download
- Versatile with comprehensive hardware accessories
DESCRIPTION
The 12” and 15” elements use coaxial drivers from Beyma – which are manufactured in Europe.
This coaxial design gives consistent coverage on both Horizontal and Vertical planes – while competitive traditional two-way line arrays do not have consistent coverage in one axis at least by design. WLA-1 coaxial design gives consistent coverage and is unique.
EVO-Fold reduces the usual phase issues that traditional 2-way line arrays have due to them having the drive units physically some distance apart in the array. One specially-designed coaxial mid-high frequency driver is loaded to a unique EVO-Fold horn. The EVO-Fold horn combines a unique folded and manifold design. The most advanced FEM technology has been used to create this.
SPECIFICATIONS
| Design | Hybrid Curvature Array |
| System Type | 12″ coaxial passive |
| Configuration | two-way |
| Frequency Response (+/-3 dB) | 55 Hz – 20 KHz |
| Frequency Range (- 10 dB) | 35 Hz – 25 KHz |
| Sensitivity 2.83 V/1 m | 101 dB |
| Calculated Maximum SPL @ 1 m | 133 dB |
| System Peak SPL | 139 dB** |
| System Rated Impedance | 8 Ω |
| Voice Coil Size | 101.6 mm / 4.0” |
| LF Frame Material | Aluminium |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Coil Size (mm / inches) | 72.2 mm / 2.87″ |
